Funciones L2
MAC Address Table: 8K
Flow Control
Jumbo Frame up to 13,000 Bytes
IGMP Snooping
MLD Snooping
Spanning Tree Protocol
Loopback Detection
802.3ad Link Aggregation
Port Mirroring
Multicast Filtering
VLAN
802.1Q Tagged VLAN
VLAN Group
Management VLAN
Asymmetric VLAN
Auto Voice VLAN
Quality of Service (QoS)
802.1p Quality of Service
Queue Handling
4 queues per port
Bandwidth Control

Access Control List (ACL)
Max. 50 profiles
Max. 200 rules shared by profiles
Single or multiple ports (each rule)

Seguridad
Broadcast/Multicast/Unicast Storm Control
Static MAC
D-Link Safeguard Engine
DHCP Server Screening
Trusted Host
ARP Spoofing Prevention
SSL 2
Smart Binding

- Puerto 1~4: máximo power es de 30W y 15.4W por defecto
- Puerto 5~24 máximo power es de 15.4W y por defecto es 15.4W

- Capacidad de flujo: 12.8 Gbps
- Modo de reenvío: Store and Forward
- Web-based GUI compatible con los siguientes navegadores: IE6/7 or later version, Netscape 8 or later version Mozilla
- Firefox 1.5/2.0 or later version
Consumo
- Máximo: 254  Watts (PoE on),  26.4 Watts (PoE off)
- Standby : 17.6 W/110V, 15.1 W/240V
Fuente de Alimentación
- Internal universal power supply
- AC Input: 2.215A@115V, 1.293A@230V
- Dimensiones: 440 x 250 x 44 mm
- Peso: 3.69 kg
- Número de ventiladores: 3
- Disipación de calor: 866.65 BTU/hr
- Ruido:53.9 dB (A)
